Prodigit 33516F超高功率直流电子负载(12600W,840A,60V)

  • 制造商: PRODIGIT
    Model: 33516F
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Power: 12600W
Current: 0~840A
Voltage: 0~60V
Min.Operation Voltage: 0.6V@840A
CC mode:
  Range: 0~84A/840A
  Resolution: 1.4mA/14mA
  Accuracy:    ±0.1%
CR mode:
  Range: 0.0012~0.0714~4284Ω
  Resolution: 0.0003mΩ/0.23mS
  Accuracy:    ±0.2%
CV mode:
  Range: 6V/60V
  Resolution: 0.1mV/1mV
  Accuracy:    ±0.05%
CP mode:
  Range: 1260W/12600W
  Resolution: 21mW/210mW
  Accuracy:    ±0.5%
Measurement mode (Load):
  Voltage: 0 ~ 6V/60V, ±0.025%
  Current : 0 ~ 84A/840A, ±0.1%
  Power : 0 ~ 12600W, ±0.125%
Protections:
  Over voltage: 105%
  Over current: 105%
  Over power: 105%
  Over temp.: Yes
Short circuit current: 840A
Dimension (HxWxD): 1556 x 596 x 600 mm
Weight: 232.2 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN

Details

Datasheet
