Power: 50KW
Current: 0~50A/0~500A
Voltage: 0~1000V
Min.Operation Voltage: 10V@500A
Protections:
Over Power Protection (OPP): 105%
Over Current Protection (OCP): 105%
Over Voltage Protection (OVP): 105%
Over Temp Protection (OTP): Yes
CC mode:
Range: 0~52.5A/0~500A
Resolution: 0.875mA/8.75mA
Accuracy: ±0.1%
CR mode:
Range: 2280~1.9Ω/1.9~0.02Ω
Resolution: 8.7uS/32uΩ
Accuracy: ±0.2%
CV mode:
Range: 10~1000V
Resolution: 16mV
Accuracy: ±0.05%
CP mode:
Range: 5.25KW/50KW
Resolution: 0.0875W/0.875W
Accuracy: ±0.5%
Measurement mode (Load):
Voltage: 0 ~ 100V/100~1000V, ±0.025%
Current : 0 ~ 52.5A/52.5~500A, ±0.1%
Power : 0~5KW/50KW, ±0.125%
Short circuit current: 500A
Dimension (HxWxD): 1353 x 853 x 766 mm
Weight: 510 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
