PRODIGIT D750 Programmable DC Power Supply (300V; 2.5A)

Input voltage range: 85-264Vac (1Φ), 47-63Hz

Max. output power: 750W

Output voltage range: 0 ~ 300V

Output current range: 0 ~ 2.5A

Operation mode: CV / CC

Voltage rise time: < 150ms (rated load by fixed resistor)

Voltage fall time: < 150ms (full load) < 2.5s (no load)

Protection: OVP, UVL, OCP, OPP, OTP, SCP, Fan Lock

Operating temperature: 0 ~ 50°C

Cooling system: Fan Cooling

Dimensions (L x W x H): 436.7 x 214 x 43.6 mm

Weight: 4.5 Kg

AC input connector: RS232, RS485, GPIB
