带Promax DT-802备用电源模块的控制器

  • 制造商: Promax
    Model: DT-802
    保障: 12 month
    • 报价要求 报价要求
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




  • 质量承诺
  • 正品保修
  • 送货到家
  • 交易简单化

Modules

Control/Supply: Up to 7 modules DT-XXX or more (depending on version and modules)

Auto-config: Auto-detection of connected modules

Auto-link: Auto-detection of interconnection between modules

Local interface:

 LCD screen

Navigation keypad (6 keys)

3x information LEDs: On / Not ready / PSU Status

Intuitive Navigation Menu (tree type menu)

Communications

Ethernet: 10/100Mb. Via virtual serial port.

Modules: Configuration

Local: Through local interface

Remote: Through Ethernet port (PC software supplied)

Power Supply

Network voltage: 90 - 250 V AC

Network frequency: 50-60 Hz

Consumption: 300 W

Output Connector: JST B08P-XL-HDS

Amount: 4

Output voltage: +5 V, 20 A max ; +12 V, 14 A max.

Mechanical Features

Dimensions: W. 122 x H. 262 x D. 230 mm

Weight: 4.54 kg

Included accessories:

Power and control cable for 3 modules

Power and control cable for 4 modules

350 mm Power Cable for 4 modules

470 mm Power Cable for 4 modules

Installation Manual

PC Remote Control Software (Windows 2000, XP and Vista)

Spare batteries

AL-802 1 x Spare Redundant Power Supply

(each DT-802 control module incorporates two AL-802 voltage source)
