Pulsar measurement dB 超声波换能器

Sensor body material: Valox 357 U and syntactic foam face

Maximum separation: 500 m (1,640.4 ft)

Mounting connection: BSP or 1 in NPT

Enclosure protection: IP68/NEMA 6P

Operating Temperature: Standard: -40 °C to +90 °C (-40 °F to +194 °F)

Hazardous Area: -40 °C to +75 °C (-40 °F to +167 °F)

CE Approval: 2014/30/EU - EMC & 2014/34/EU ATEX Directives. Standards applied: EN 60079-0:2012+A11:2013/ EN 60079-11:2012 / EN 60079-18:2009 / EN 60079-26:2007 / EN 61326-1:2013

ATEX Approval: Standard ATEX EEx m II T6 or optional EEx ia IIC T6. FM/FMc approval. (dB50 not approved)

Intrinsic Safety: Optional

Accuracy: 0.25% or 6 mm (0.2 in) whichever is greater

Resolution: 0.01% or 2 mm (0.1 in) whichever is greater
