RenThang RF-101-MB 电阻成型机

  • 制造商: REN THANG
    Model: RF-101-MB
    来源: Taiwan
    保障: 12 month
    • 报价要求 报价要求
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




  • 质量承诺
  • 正品保修
  • 送货到家
  • 交易简单化

Body length: 3.8 - 20 mm

Body diameter: 2.3-8 mm

Shoulder: 1.2 min

Height: Fixed at 8mm or more

Lead Length: Adjustable

Support point: 2 ~ 3mm

Pitch: A + 2C

Wire diameter: 0.4-1.3 mm

Power: 110V/60Hz ; 220V/50Hz

Dimension: 1050(L), 600(W), 650(H) mm

Weight: (N.W.) 115 Kgs. (G.W. ) 150 Kgs

Performance: min. 6,600 pieces / hour

Moving control: Manual rotation, stepping intermittent, Fully automatic, three different modes for choice.


Chi tiết

FEATURES:

MB type, targets for TAPED parts fed by guides.

RF-101MB, forms and kinks leads into U shape with kinks on leads.

Tailor-made die set is available for most forming specification. Welcome to email the spec. drawing for our best solution for you.

Kink /MK type forming machine is suitable for the massive production line.

Ready-to-use setup: customers can use the machine right after receiving it.

OEM, DIP, PCBA Insertion line's most helpful equipment!

Rarely damage component leads or components body. (If it happens, please feel freel to consult us. )
