Samyon 1000 混凝土渗透阻力测试仪 (1000N)

Purpose: For determining the setting time of concrete by means of penetrations resistance measurement method.

Standard: GB/T50080, JTJ053.

Container (Top×Bottom×Depth): φ160mm×φ150mm×150mm

Max. load capacity: 1000N

Max. penetrating depth: 25mm

Speed: 2.5mm/s

Bearing areas of needle: 100 mm2, 50 mm2, 20 mm2

Penetrating point: Outer ring 9 point, Inner ring 4 point

Mode of test: Hydraulic pressure, pressure gauge measuring force

Min division: 5N

Error: ±10N

Power: 220V 50Hz 70W
