SANWA DG34a Clamp meter (100A,400MΩ)

-ACA : 100A  ± 2%  0.1A
-DCA : 100A  ± 2%  0.1A
-ACV : 600V ± 1.1% 1V
-DCV : 600V ± 1,6% 1V
- Test Voltage : 125/250/500V
-MΩ: 400MΩ  ± 3%  0.1 MΩ
-Pin  : LR03 x2
-Size: H130xW75xD 19.9mm
-Clamp Diameter : 10mm
-Mass :  160g
- Standard accessories included : Test lead ,Instruction manual

Detail

 Manual

Features:
■Lightweight approx. 160g
■Easy to use, pocket size
■ACV / DCV measurement range
■DCA / ACA measurement range
■Inorganic EL backlight
■Test leads holder with thermo plastic elastomer which is easy to reel
■Current measurement with thin U-shaped current
■sensor (7mm) at angles of 0 and 180 degrees
■Data hold
■Measurement of relative value
■With Clip adapter
Display : 3999
Sampling rate : 2 times / sec.

Option:
Carrying case : C-DG3a
Clip adapter : CL-13a, CL-15a, TL-9IC
