Test voltage (DC V): 250V/ 500V/ 1000V
Measuring ranges: 0-100MΩ/ 0-200MΩ/ 0-400MΩ /± 5%
Short circuit terminal current: >1.0mA
Continuity: yes
Measuring AC Voltage: 0-500V AC/± 3%
Dimensions: 250(L) × 190(W) × 110(D)mm
Weight: 1400g
Power source 1.5V (AA) × 8
Detail
|
FEATURES |
● High quality Taut Band movement. ● Three insulation test voltages(DC) : 250V, 500V, 1000V. ● Two continuity test on "low ohms" : 500Ω & 3Ω. ● Compact and lightweight. ● AC voltmeter with linear scale up to 600 Vac. ● 200mA continuity short circuit current. ● 1mA test current on insulation test at nominal voltage. ● Automatic discharge of capacitive and inductive circuit with charge stored in the circuit under test. ● Live warning and display or external voltage presence. ● Fuse, air gap, crowbar and overload protected. ● On line battery monitoring shows if battery is ok. ● Auto-null of the test leads on continuity tests. ● Low battery consumption. ● Mirror scale. ● Push and turn locking switch for continuous and hand free testing. ● Designed for meet international standards. ● Supplied with high quality test leads. ● BS 16 edition. |
|
SPECIFICATIONS |
|
|
|
|
Insulation Resistance |
|
|
Test voltage (DC V) |
250V / 500V / 1000V |
Output voltage on open circuit |
Rated test voltage +10% |
Measuring ranges |
0-100MΩ / 0-200MΩ / 0-400MΩ |
Mid-scale value |
1MΩ / 2MΩ / 4MΩ |
Scale multiplier |
×1/2 / ×1 / ×2 |
Accuracy |
± 5% of indicated value |
Output short- circuit current |
1.3mA |
Continuity |
|
|
Measuring ranges |
3Ω / 500Ω |
Output short- circuit current |
≥200 mA |
Accuracy |
± 1% of scale length |
AC Voltage |
|
|
Range |
0-500V AC |
Accuracy |
± 3% of scale length |
General |
|
|
Voltage warning |
Warning light circuit live lit From 90Vdc / 70Vac, Buzzer beep from 24V ac/dc |
Battery check |
Battery check indicate good batteries from 8Vdc to 13Vdc during a load test of 205mA. Battery OK : battery ok led lit from 6.5Vdc and is operative while testing. |
Dimensions |
250(L) × 190(W) × 110(D)mm |
Weight (battery included) |
Approx. 1400g |
Power source |
1.5V (AA) × 8 |
Safety standard |
EN 61010-1 CAT III 600V EN 61326-1 |
|
|
|
