Measuring ranges:
0-200.0mΩ in steps of 100μΩ
0-2000mΩ in steps of 1mΩ
0-20.00Ω in steps of 10mΩ
0-200.0Ω in steps of 100mΩ
0-2000Ω in steps of 1Ω
Accuracy: ±0.5% of reading ±2 digits
Test current:
1mA=>2000Ω range
10mA=>200 / 20Ω ranges
100mA=>2000m / 200mΩ ranges
Test current accuracy: ±0.1%
Protection fuses:
Mains = 0.5A, HBC, 5 × 20mm, DIN
Current = 0.5A, HBC, 5 × 20mm, DIN
Voltage = 0.5A, HBC, 5 × 20mm, DIN
Maximum output voltage (C1~C2): 20V
Dimensions: 250(L) × 190(W) × 110(D)mm
Weight: 1530g
Safety standard: EN 61010-1 CAT IV 20V
EN 61326-1
