SMAC APA-80V C式单点压力机

Capacity (Ton): 80

Rated tonnage point (mm): 4

Speed changing (x.p.m): 35-80

Stable speed (mm): 65

Stroke (mm): 150

Die height (mm): 340

Slide adjustment (mm): 75

Slide area (mm): 500x420x70

Bolster area (mm): 1000x550x90

Shank hole (mm): F50

Main motor (kw): 7.5

Air pressure (kg/cm2): 6

Presses precision: GB(JIS)1CLASS

Presses dimension (mm): 1800x1180x2800

Presses weight (Ton): 6.5

Die cushion Capacity (Ton): 3.6

Stroke (mm): 70

Die cushion effective area (mm2): 450x310

Slide adjust device (HP): Electrical driving
