SOLID NDT SD400 钢筋定位器 (6mm~79mm, 7mm~180mm)
制造商: SOLID NDT Model: SD400 来源: Taiwan - 报价要求
- 报价要求
- 联系
Tester Type: GW-50+
Bar diameter application range(mm): Φ6~Φ50
Maximum value permissible error of Bar diameter: ≤±1
Protective layer thickness measuring range: 75±0.3mm
The first measuring range(mm): 6~90
The second measuring range(mm): 7~180
The maximum error of reinforced protective layer thickness test value:
- The first measuring range(mm):
+ 6~59: ≤±1
+ 60~69: ≤±2
+ 70~79: ≤±4
- The second measuring range(mm):
+ 7~79: ≤±1
+ 80~119: ≤±2
+ 120~180: ≤±4
Details
