SUTO S350 露点监测器 (-20~+50 °C TD / -50 ~+20 °C TD)

Measurement

Dew Point

Accuracy: ±2 °C Td

Selectable units: °C, °F

Measuring range (model depending): -50 ... +20 °C Td; -20 ... +50 °C Td

Sensor: Polymer

Response time t90 (@ 4l/min): -50 °C Td -> -20 °C Td = 20 sec; 0 °C Td -> -40 °C Td = 120 sec

Temperature

Accuracy: 0.3 °C

Measuring range: -30 ... +70 °C

Sensor :NTC

Reference conditions

Selectable conditions Pressure Dew Point

Signal / Interface & Supply

Analog output

Signal: 4 ... 20 mA 3-Wire

Scaling: -50 ... +20 °C Td or -20 ... +50 °C Td

Load: 250R

Update rate: 3 / sec

Supply

Voltage supply (model depending): 100 ... 240 VAC ; 50/60 Hz 24 VDC

Current consumption (model depending): 40 mA @ 220 VAC; 120 mA @ 24 VDC

General data

Configuration

PC Software: S4C-Display Software

Others: Instrument comes pre-configured Plug & Play

Display

Integrated: LCD Display, indicates values and alarms

Material

Process connection: Stainless steel 1.4301 (SUS 304)

Housing: ABS, Aluminium alloy

Sensor: Polymer

Metal parts: Sinter Filter (stainless steel)

Miscellaneous

Electrical connection: Screw terminals

Protection class: IP65

EMC: IEC 61326-1

Process connection: 6 mm quick connector

Weight: 520 g

Operating conditions

Medium: Non-corrosive gases

Medium quality: ISO 8573-1: 4.6.3 or better

Medium temperature: -30 ... +70 °C

Medium humidity: ≤ 20 °C Td or ≤ 50 °C Td (model depending)

Operating pressure: 0.3 ... 1.5 MPa

Ambient temperature: -10 ... +40 °C

Ambient humidity: 0 ... 100 % rH

Storage temperature: 0 ... +40 °C

Transport temperature: -30 ... +70 °C
