Tektronix TTR503A 矢量网络分析仪（3GHz，2端口）
制造商: TEKTRONIX Model: TTR503A 保障: 12 Month - 报价要求
- 报价要求
- 联系
Frequency range
TTR503A 100 kHz to 3.0 GHz
TTR506A 100 kHz to 6.0 GHz
Ports 2-ports, Type-N female connectors
Measurements Two-port, two-path S-parameters (S11, S12, S21, S22) and related measurements.
Connectivity USB 2.0
Software VectorVu-PC™ (requires Windows® 7/8/10, 64-bit)
100 to 240 V AC, 50/60 Hz
Output: + 5 V ±1% 4 A maximum
Physical characteristics
Length: 11.25” (28.58 cm)
Width: 8.125” (20.64 cm)
Depth: 1.75” (4.45 cm)
Weight: 3.5 lbs. (1.59 kg)
