Telide HPB-1300-S010P4BS034 气动气体增压动力装置 (6.9bar, 264bar)

Tubular frame unit.

Components include booster, air filter, pressure regulating valve, high pressure needle valve, pressure gauge, explosion-proof solenoid valve, etc.

Hydrogen pressurization specific unit. Outlet pressure range of booster can be set. Booster sets up automatically when outlet pressure reaches lower value, automatically stop when outlet pressure reach upper value.

Max. Driving air pressure 6.9 bar, max. Output air pressure 264 bar.

Dimensions(L×W×H): 30×19×17 inch.

Weight:94 lbs.
