Telide HPU-1302 油冲击试验台 (0.5~70MPa)

Pulse pressure range: 0.5~70MPa (hose assemblies)

                                 0.5~6MPa (condenser, evaporator)

Pressure measurement accuracy: ±0.5%FS

Pressure control accuracy: ±2%FS

Pressure waveform: trapezoidal waveform, sinus waveform, triangular waveform

Impulse frequency: ≤2.0Hz (hose assemblies)

                              ≤3.0Hz (condenser, evaporator)

Test medium: Refrigerant oil, PAG oil, hydraulic oil, silicone oil, etc

Medium temperature range: -40℃~150℃ arbitrary setting (trapezoidal wave)

Ambient temperature range: -40℃~150℃ arbitrary setting
