Telide HSU-1100 气动动力装置 (500~33500psi)

Standard unit for general use.

Components include S-216-( ) pump (ten ratios), air filter, pressure regulator and lubricator, air Shut-off valve, muffler, liquid bleed valve, air pressure gauge, liquid-filled pressure gauge with quick disconnect fitting.

Available pressure ranges: from 500 to 33,500 psi.

Steel powder coated (or stainless steel) base has four mounting holes.

Dimensions (WxDxH): 22x14x11 in.

Weight: 40 lbs.

Datasheet
