Operating Voltage(Un): 140V-270V AC { N - Un }
Operating Frequency: 50/60 Hz
Operating Power: <6VA
Operating Temperature: -20°C.....+55°C
Voltage Measuring Range: 1V-500V AC
Current Measuring Range: 70mA - 5,5A AC
Display: (3 digit) 6x Displays + 9 Leds
Connection Type: Plug-in terminal
Cable Diameter: 1,5mm²
Weight. Max: 325gr
Panel Hole Sizes: 91x91mm(EM-XXX)
Mounting: Assembled on the din rail
Operating Altitude: <2000meter
Chi tiết
Datasheet
