TES AVM-01 风速计 (0.0-45.0 m/s)
制造商: TES Model: AVM-01 - 报价要求
- 报价要求
- 联系
Range of wind velocity
Range: 0.0-45.0 m/s, Resolution: 0.1 m/s, Threshold: 0.5 m/s, Accuracy: ±3% ±0.3 m/s
Range: 0-8800 ft/min, Resolution: 10 ft/min, Threshold: 60 ft/min, Accuracy: ±3% ±40 ft/min
Range: 0.0-88.0 knots, Resolution: 0.1 knots, Threshold: 0.6 knots, Accuracy: ±3% ±0.4 knots
Range: 0.0-140.0 Km/hr, Resolution: 0.1 Km/hr, Threshold: 1.0 Km/hr, Accuracy: ±3% ±0.8 Km/hr
General Specifications:
Bearing: Sapphire jewel bearing
Mounting Nut: 1/4"x20
Operating temperature:
Meter: 0°C~50°C (32°F~122°F)
Vane: 0°C~60°C (32°F~140°F)
Operating temperature: less than 80% RH
Operating Pressure: 500 mB ~ 2 Bar
Storage Temperature: -40°C ~ 60°C (-40°F ~ 140°F)
Power Consumption: Approx. 6 mA
Battery Type: 9V
Battery Life: 50 hours (for 300mA-hrs battery)
Averaging Period for Wind Speed Measurement:
m/s: 0.6 sec.(approx.)
ft/min: 1.2 sec.(approx.)
knots: 1.2 sec.(approx.)
km/hr: 2.2 sec.(approx.)
mph (optional): 1.4 sec.(approx.)
Dimension: Meter 88x 168x 26.2mm (3.46"x 6.61"x 1.03")
Dimension: Vane 66x 132x 29.2mm (2.60"x 5.22"x 1.15")
Weight: 350g / 12.34oz (battery included)
Accessories:
Carrying case x 1
Users manual x 1
9V Battery x 1
