THORLABS ITC4020 组合激光二极管台式控制器 (20 A / 225 W)

Digital I/O Port

Number of I/O Lines: 4 (Separately Configurable)

Input Level: TTL or CMOS, Voltage Tolerant up to 24 V

Output Level (Source Operation): TTL or 5 V CMOS, 2 mA Max

Output Level (Sink Operation): Open Collector, up to 24 V, 400 mA Max


USB 2.0: According to USBTMC/USBTMC-USB488 Specification Rev. 1.0

Protocol: SCPI Compliant Command Set

Drivers: VISA VXIpnp™, MS Visual Studio™, MS Visual™, NI LabVIEW™, NI LabWindows/CVI™

General Data

Safety Features: Interlock, Inhibit, Keylock Switch, Laser Current Limit, Laser Power Limit, Soft Start, Short Circuit when Laser Off, Adjustable Laser Overvoltage Protection, Over Temperature Protection Temperature Window Protection

Display: LCD 320 x 240 Pixel

Connector for Laser, Photodiode, Interlock, and Laser On Signal: 13W3 Mixed D-Sub Jack (female)

Connector for Sensor, TE Cooler, TEC On Signal: 17W2 Mixed D-Sub Jack (female)

Connectors for Control Input / Output: BNC

Connector for Digitial I/O: Mini DIN 6

Connector for USB-Interface: USB Type B

Chassis Ground Connector: 4 mm Banana Jack

Line Voltage / Frequency: 100 to 120 V and 200 to 240 V ±10%, 50 to 60 Hz

Maximum Power Consumption: 900 VA

Mains Supply Overvoltage: Category II (Cat II)

Operating Temperature: 0 to 40°C

Storage Temperature: - 40 to +70°C

Relative Humidity: Max. 80% Up to 31°C, Decreasing to 50% at 40°C

Pollution Degree (Indoor Use Only): 2

Operation Altitude: <2000 m

Warm-up Time for Rated Accuracy: 30 min

Weight: 6.4 kg

Dimensions w/o Operating Elements (W x H x D): 263 mm x 122 mm x 307 mm (10.4" x 4.8" x 12.1")

Dimensions /w Operating Elements (W x H x D): 263 mm x 122 mm x 345 mm (10.4" x 4.8" x 13.6")

All technical data valid at 23 ± 5°C and 45 ± 15% relative humidity. Subject to change without notice.
