TIME 6206 洛氏硬度计 (3,18 ~ 653HBW)
制造商: TIME Model: 6206 来源: China 保障: 12 Month - 报价要求
- 联系
Test Force:
612.9n(62.5kgf), 980.7n(100kgf), 1226n(125kgf), 1839n(187.5kgf), 2452n(250kgf), 4903n(500kgf), 7355n(750kgf), 9807n(1000kgf), 14710n(1500kgf), 29420n(3000kgf)
Test Range: 3.18~653HBW
Loading Method: Automatic (Loading/Dwell/Unloading)
Hardness Reading: Indentation Displaying and Automatic Measuring on Touch Screen
Computer: CPU: Intel I5,Memory: 2G,SSD: 64G
CCD Pixel: 3.00 Million
Conversion Scale:
HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15n, HR30n, HR45n, HR15T, HR30T, HR45T, HS, HBS, HBW
Data Output: USB Port, VGA Interface, network Interface
Shifting between Objective and Indenter: Automatic Recognition and Shifting (Three Indenters, Two Objectives)
Objective 1×, 2×
Resolution: 3μm, 1.5μm
Dwell Time: 0~95s
Max. Height of Specimen: 290mm
Throat: 150mm
Power Supply: AC220V, 50Hz
Execute Standard: ISO 6506, ASTM E10-12, jIS Z2243, GB/T 231.2
Dimension:
700×380×1000mm
Packing Dimension: 920×510×1280mm
Weight
net Weight: 200kg
Gross Weight: 230kg
Standard Delivery
Main unit
Ф2.5mm, Ф5mm, Ф10mm Ball Indenter
Large Plane Test Table
Fuse 2A
Hardness Block 150~250 HBW 10/3000
Inner Hexagon Spanner 3mm
Usage Instruction Manual
1×, 2× Objective
Small Plane Test Table
V-shaped Test Table
Power Cable
Hardness Block 150~250 HBW 5/750
Anti-dust Cover
