TOB TOB-AWM-3270C Supercapacitor And Cylinder Battery Winding Machine (6KW)

Source voltage: AC220V/50Hz/Single phase. Customized according country request

Power: 6KW

Compressed air: 0.45~0.6Mpa

Operating environment

Temperature: 20~35℃

Humidity: 30~55%HR

Tab welding skewness: ±3°

Welding tension: ≥15N

Cutter knife life

Cathode 500000 times with repair

Anode 200000 times with repair

According to tab thickness

Output: 4-5pcs/min according to battery model

Dimension (L*W*H): 2400*1700*1900mm

Weight: 1500kg
