TOB TOB-BE-6045 Battery Crush Testing Machine (1500W)

Source voltage: AC 380V, 50/60HZ

Power: 1500W

Dimension(W*D*H): 680*570*1740mm

Weight: 200kg

Controller dimension (W*D*H): 330*330*1040mm

Max pressure: 1000N-13KN, Customized

Upper pressure plate diameter: 15cm

Pressure error: 1%

Power model: Hydraulic

Max test space(D*W*H): 200*200*200mm

View window dimension: 200*200mm, 10mm thickness Double explosion-proof glass

Anti explosion case: Bottom is provided with four universal wheels, and can move freely

Exhaust fan port: 15mm diameter
