TOB TOB-BE-6045C 计算机控制动力电池破碎试验机 (5000W)

Source voltage: 3∮5W  380V 50HZ 5000W

Dimension(W*D*H): 1200W*1100D*1800H

Weight: 1500kg

Max pressure: 10t,20t,30t,50t,80t,100t

Force value Resolution: 1/100,000

Force error: ±1%

Drive mode: Electro-hydraulic servo drive

Extrusion speed: 0.1~500MM/S(Adjustable)

Unit Conversion: KG/N/LB

Test space: 600W*600D*600H MM (customized)

Voltage acquisition frequency: 200times/S

Temperature acquisition frequency: 2 channels,2times/S

Test hole: On the left,50mm diameter hole attached a stainless steel lid

Visual window: Double-proof glass 300*300MM and affixed with explosion-proof film, and with steel mesh
