TOB TOB-BE-6045C Computer Control Power Battery Crush Testing Machine (5000W)

  • 制造商: TOB
    Model: TOB-BE-6045C
    来源: China
    保障: 12 month
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Source voltage: 3∮5W  380V 50HZ 5000W

Dimension(W*D*H): 1200W*1100D*1800H

Weight: 1500kg

Max pressure: 10t,20t,30t,50t,80t,100t

Force value Resolution: 1/100,000

Force error: ±1%

Drive mode: Electro-hydraulic servo drive

Extrusion speed: 0.1~500MM/S(Adjustable)

Unit Conversion: KG/N/LB

Test space: 600W*600D*600H MM (customized)

Voltage acquisition frequency: 200times/S

Temperature acquisition frequency: 2 channels,2times/S

Test hole: On the left,50mm diameter hole attached a stainless steel lid

Visual window: Double-proof glass 300*300MM and affixed with explosion-proof film, and with steel mesh
