TOB TOB-BE-9002D 电池打钉试验机 (1000N~5000N)

Pressure range: 1000N~5000N Customized

Dimension: W1000*D800*H2100MM

Weight: 250kg

Controller dimension: W350*D350*H1040MM

View window dimension: 800*300MM double explosion-proof glass

Source voltage: Three-phase 5W ,380V, 50HZ

Power: 1KW

Nailing mode: Hydraulic pressure

Nailing force: ±1% accuracy

Max testing size: 500W*500D*500H MM adjustable

Nailing speed: 10-40MM/S, adjustable,

Nailing speed error: ±0.1MM/S

Unit Conversion: Kg/N/Lb

Test hole: 50 mm diameter test hole on the left,  attached a stainless steel lid
