TOB TOB-DZF-6020-HT 真空干燥箱 (25L 500℃)

Chamber and Door

  The chamber is structured by Stainless Steel (1Cr18Ni9Ti)

Inner Chamber size: 300mm(L) x 300mm(W) x 280mm(H); (12 x 12 x 11, 25 Liter)

Aluminium Plate with thermal insulation.

A good vacuum seal is achieved by silicone door gasket and positive latch door.

02 stainless steel shelves are included to facilitate processing efficiency.

Working Voltage: 110 or 240VAC (20Amps circuit breaker is required)

Power Consumption: 1400 W

Heating Rates: 2C/min

Temperature Controller

30 segments programmable temp. controller

Built-in over-temperature protection, PID precise temperature control

Temperature Stability: +/- 1°C

Float Meter: 200 ~ 2000 ml/min

Dimensions: 700mm(L) x 500mm(W) x 525mm(H)

Shipping Weight Dimensions: 48"(L) x 40"(W) x 31"(H); 310 Lbs / 140.61 kg after crating
