TOB TOB-LCF-1700C Crucible Furnace (1700℃,6.5KW,110V/220V)

Heating mode: Silicon molybdenum bar heating

Furnace effective size: Φ200*180mm

Working temperature: ≤1700℃

Max temperature: 1700℃

Temperature rising speed: 10℃/min

Temperature accuracy : ±1℃

Source voltage: AC110V/220V   50/60HZ

Heating power: 6.5kw

General dimension: 480*500*950mm

Weight: 110kg

Structure

51 steps programmable intelligent control

Fiber inner materials for temperature up to 1700℃

Lift model at bottom, simple for operation

Standard configure

1pcs crucible tongs, 1pair High temperature gloves,

2pcs heating elements, 1pcs thermocouple.

Detail

Datasheet
