TOB TOB-R-203 电池电阻测试仪 (0-29.99V, 1-2000 mΩ)

  • 制造商: TOB
    Model: TOB-R-203
    来源: China
    保障: 12 month
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Source voltage: AC110V-240V, 50/60HZ

Power: 10-30W

Testing speed: 100ms

Advantages

Can connect with computer

Suitable varies kinds battery and battery core

Buzzer alarm

Voltage test V1

Voltage range : 0-4.999V

Minimum resolution : 0.001V

Accuracy : ±0.002V

Voltage test V2

Voltage range : 0-29.99V

Minimum resolution : 0.01V

Accuracy : ±0.01V

Resistance test R1

Resistance range : 0.1—200 mΩ

Minimum resolution : 0.1mΩ

Accuracy : ±0.5 mΩ

Resistance test R2

Resistance range :1—2000 mΩ

Minimum resolution : 1mΩ

Accuracy : ±2 mΩ

Suitable batteries

Lithium battery, lithium pouch cell(Lithium polymer battery),

Nickel metal hydride, nickel cadmium battery, lead-acid battery and so on.

Dimension: 250*190*90mm

Weight: 2kg

Details

Datasheet
