TOB TOB-W602 Battery Pack Test Equipment For 1-2 Series Battery (0-10V,1000 mΩ)

  • 制造商: TOB
    Model: TOB-W602
    来源: China
    保障: 12 month
    • 报价要求 报价要求
  • 联系
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




Source voltage: AC110V/220V, 50/60HZ

Power: 10-50W

Dimension (L*W*H): 290mm(L)*270mm(W)*100mm(H)

Weight: 4kg

Voltage test (V1)

Range: 0—5 V, Resolution: 0.001V, Accuracy: 0.2% + 3

Range: 0—10 V, Resolution: 0.01V, Accuracy: 0.3% + 5

Charging   (CHA): Range: 50—2000mAh, Resolution: 1mA, Accuracy: 2% + 3

Discharging: Range: 50—200mAh  Resolution: 1mA Accuracy: 1% + 5

Over discharging current (OVC):  Range: 0—20 A   Resolution: 0.01A  Accuracy: 2% + 3

Internal Impedance (IMP):  Range: 0—999 mΩ  Resolution: 1mΩ  Accuracy: ±1mΩ

Short-circuit protection (SPT):  Range: 0—99.9 mS  Resolution: 0.1mS  Accuracy: 2% + 3

Thermistor (R1/R2):  Range: 0—999.9 kΩ  Resolution: 0.1kΩ  Accuracy: 2% + 3

Capacity:  Range: 0—9999 mAH  Resolution: 1mAH   Accuracy: 3%


Details

Datasheet
