UNI-T UT513A 绝缘电阻测试仪 (5000V,1TGΩ)

Test voltage: 5000V

Insulation resistance:

500V 0.5MΩ~20GΩ ±(3%+5)

1000V 1MΩ~40GΩ ±(3%+5)

2500V 2.5MΩ~100GΩ ±(3%+5)

5000V 5MΩ~1000GΩ ±(3%+5)

Short-circuit current: ~3.5mA

Comparison function: Yes

Polarization index (PI): Yes

Dielectric absorption ration (DAR): Yes

Display count: 10000

Auto range: Yes

DC voltage: 600V ±(2%+3)

AC voltage: 600V ±(2%+3)

USB data transmission: Yes

Data storage: 18

High voltage prompt: Yes

LCD backlight: Yes

Analog bar: Yes

Low battery indication: Yes

Overload prompt: Yes

Light alarm: No

Buzzer alarm: Yes

Auto power off: Yes

Meets IEC 61557: 61557-1:2007, 61557-2:2007

Category ratings: CAT III 600V

Power: 1.5V battery (LR14) x 8

Display: 123mm x 58mm

Product color: Red and grey

Product net weight: 2kg

Product size: 202mm x 155mm x 94mm

Standard accessories: 2pcs of one plug test lead to one alligator clip (black and green), 1pcs of two plugs test lead to one alligator clip (red), batteries, USB  cable, PC software CD, power adaptor
