VICTOR 850C 非接触式电力测试仪 (ø1.6mm-ø16mm)

Vised wire size: Outer diameter ø1.6mm-ø16mm

Power supply: DC 3V (AA/LR6*2 alkaline dry batteries, continuously working for 70 hours)

Performance-guarantee range: AC70-1000V, 45-65Hz (sine wave continuously input)

LED display

【Positive Phase Sequence】The four phase-sequence lamps blink in order (clockwise)

【Negative Phase Sequence】The four phase-sequence lamps blink in order (counterclockwise).

【Line-voltage Indication】L1,L2,L3 lamp light up

【Default Phase】L1/L2/L3 lamp is off

【Open Circuit】L1/L2/L3 lamp is off

Buzzer

【Positive Phase Sequence】The buzzer sounds intermittently

【Negative Phase Sequence】The buzzer sounds continuously

Power indication: POWER indicator light up after turn on; LOW BATTERY lamp light up if the battery needs to be replaced

Magnetic force: Instrument base plate is provided with four magnets, suction hanging in the electrical box, can withstand 800g quality

Auto Power off: The power will be turned off automatically if the instrument remains idle for 5 minutes after the power is turned on

Clamp lead wire length: 0.6m

Dimension: 70W×75H×30D (mm)

Weight: About 200g (including batteries)

Max. rated voltage: AC 1000V

Dielectric strength: 5.4kVrms

Max. rated power: 300mVA

Accessories: Batteries LR6: 2pcs bag: 1pc rope: 1pc
