VICTOR 88B 数字万用表 (1000VDC, 750VAC, 20ADC/AC, True RMS)

DC Voltage: 200mV/2V/20V/200V/1000V ±(0.5%+3)

AC Voltage: 2V/20V/200V/750V ±(0.8%+5)

DC Current: 200uA/2mA/20mA/200 mA/20A ±(0.8%+4)

AC Current: 20mA/200 mA/20A ±(1.0%+5)

Resistance: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ/200MΩ ±(0.8%+3)

Capacitance: 20nF/200nF/2uF/20uF/200uF/2000uF ±(2.5%+20)

Frequency: 10Hz/100Hz/1KHz/10KHz/100KHz/1MHz ±(3.0%+15)

Celsius: (-20 ~ 1000)℃ (0 ~ 1832)℉ ±(1.0%+3)


Special Function

Diode test

Continuity buzzer

Low battery indication

Data hold

Auto power off

Backlight

Function protection

Restorable Fuse protection

Shock proof protection

Input impedance: 10MΩ

Sampling rate: 3 times/s

AC frequency response: (40-400)Hz

Operation way: Manual range

Max. Display: 1999

LCD size: 65×45mm

Battery: 9V (6F22)



General Characters

Product Net Weight Approx. : 400g(include battery )

Product Dimension: 189×97×35mm

Standard Accessories: Test leads , battery ,instruction manual,TPO1 temperature probe
