大容量在线ADR X射线测试柜VisiConsult XRHGantry CR

Manufacturer: VisiConsult

Model: XRHGantry CR

Origin: Germany

Warranty: 12 months


Max. part size (mm - Ø x height): 3800 x 1900

System size (mm L x W x H): 5900 x 3605 x 3500


System weight (kg): 4800

Console weight (kg): 175

Console size (mm): 1200 x 950 x 1600

Energy (kV): up to 450

Horizontal motion TX (mm): 3800

Magnification TY (mm): 2300

Focus Detector Distance FDD (mm): 100 - 2000


Focus Object Distance FOD (mm): 100 -2000

Vertical motion TZ (mm): 2000

Tilt RX (deg.): + 60°/ - 90° manuell

Part rotation RZ (deg.): + / - 10°


Details

Datasheet
