Wey Hwang WH-CIW Chip Inductor Winding Machine (3000 RPM)

Control System: Panasonic FPΣ System

Spindle Control

Winding Spindle: 3 Axis AC Servo Motor

Welding Part: 2 Axis Stepping motor

Welding Machine: Electric Component Welding Machine

a. Output adjust range 0 – 300

b. Touch time: 3ms

User Interface: DELTA DOP - A57

Cycle time: About 6s / PC (Depends on winding turns)

Winding Speed: 3000 RPM (Max)

Spindle Angel: 360∘/ Turn,Setting unit 0.36∘

Wire Size: 0.03mm - 0.1mm

Nozzle movement: 0.001mm

Machine Dimension: 107( L ) x 80(W ) x 188( H ) cm

Machine Weight: 120 KGS
