Yamato CTA812S 冷却水循环机 (189W, 分开式)

System: Separated type, Air cooled electronic system, External open circulation

Operating temperature range: 0 to +70℃

Temp. adjustment accuracy: ±0.1℃

Cooling capacity: 163 kcal/h (189W)

Performance pump capacity (50 Hz) Maximum flow ratemax. flow (50/60Hz): 11 L/min

Performance pump capacity (50 Hz) Maximum discharge pressure: 78.4kPa

Material of cooling/heating unit, liquid contact part: Stainless steel (SUS304)

Circulation port nipple diameter: O.D.: 12.7mm

Number of thermo module: 8

Accessories: Circulation heat insulation hose (ID 11.5mm 1m×2pcs.), Stacking support

External dimensions(W×D×H mm): 361×410×265

Remarks(dimensions): Seperated type

Power Source: AC220V

Single phase with step down transformer

Weight: 27kg
