Yamato CTW812 冷却水循环机 (291W, 结合式)

System: Integrated type, Water cooled electronic system, External open circulation

Operating temperature range: -10 to +70℃

Temp. adjustment accuracy: ±0.1℃

Cooling capacity: 250 kcal/h (291W)

Performance pump capacity (50 Hz) Maximum flow ratemax. flow (50/60Hz): 11 L/min

Performance pump capacity (50 Hz) Maximum discharge pressure: 78.4kPa

Material of cooling/heating unit, liquid contact part: Stainless steel (SUS304)

Circulation port nipple diameter: O.D.: 12.7mm

Number of thermo module: 8

Accessories: Circulation heat insulation hose (ID 11.5mm 1m×2pcs.),Heat radiation water hose (ID12mm 3m×1pc.)

External dimensions(W×D×H mm): 331×480×380

Remarks(dimensions): Integrated type

Power Source: AC220V

Single phase with step down transformer

Weight: 27 kg
