Yamato DF612 Fine Oven (216L, 15A)

System: Forced convection and ventilation

- Operating temperature range: RT +15~260°C

- Temp. control accuracy: ±0.1°C (at 260°C) JTM K05

- Temp. distribution accuracy: ±1.5°C (at 260°C) JTM K05

- Max. temp. reaching time: Approx. 60 min

Temp. control system: PID control with a micro computer

Heater: Stainless pipe heater

Blower fan / Motor: Axial flow fan / Capacitor motor

Cable port: I.D. 33 mm×1 pc. (rear)

Heat insulating material: Glass wool

Internal dimensions (W×D×H): 600×600×600 mm

External dimensions (W×D×H): 1200×780×1000 mm

Internal capacity: 216L

Power supply: Single phase: AC220V, 15A

Weight: 156 kg

Stainless wire shelf / bracket: 3 pcs / 6 pcs
