Yamato AHS191H 超净工作台 (39 m3/min)

Air flow direction: Horizontal

Cleanliness: Class 100

Blow-off air speed (m/sec): Apprx. 0.40 at early stage, Apprx. 0.20 final

Illuminance (lx): 1000 (in the center of working face)

Load bearing of working face: 50kg (static load)

Air volume: Approx. 39 m3/min

HEPA Filter (mm): 915 x 915 x 65/2pc 0.3μm DOP scan test 99.99 % or more

Front filter (mm): 400 x 400 x 15/2pc.

Socket: AC220V or AC115V 5A 2 outlets with grounding wire 2 (total capacity is 5A)

Flourescent lamp: 40W x 4pcs.

Blower (single phase): 150W x 2

Working surface level adjustment: Using adjusting foot (-18~+40mm)

Display of pressure difference: Differential pressure gauge

Accessories: Fixing fittings of adjusting foot x 4

Optional item: Air velocity controller: displays blow-off air speed and with variable air speed device

Internal dimensions(H mm): 875mm

External dimensions(W×D×H mm): 1910×770×1725mm

Power Source: AC220V 15A

Weight: 310kg
