Rating: 125V/20MΩ, 250V/50MΩ, 500V/100MΩ
Effective Measuring range: 0.01–20MΩ/ 0.01–50MΩ/ 0.05–100MΩ
Central Scale Value: 0.5MΩ/ 1MΩ/ 2MΩ
AC Voltage Measuring range: 0–600V
Low limit measuring resistance: 0.125MΩ/ 0.25MΩ/ 0.5MΩ
Rated current: 1 mA
Scale length: Approx. 86 mm (outer scale)
AC voltage measurement: AC voltage measurement is possible wherever the rotary switch is positioned.
Discharge function: The tester automatically begins discharge when you turn off the MEAS switch. The pointer swings if there is any residual voltage in the circuit under test. You can make sure discharge is complete by checking that the pointer swings back to the infinite (∞) scale value. Under this condition, the tester is ready to enter voltage measurement mode.
Dimensions (main unit): Approx. 120 (W)x 110 (H) x 60 (D) (mm)
Weight: Approx. 500 g (including batteries)
Batteries: Six AA (LR6 or R6) batteries
Standard Accessories: Earth and Line probes 98007, Carrying case B9075MU, User's manual, Batteries
