Major application: Peeling test
Max. force: 50N (5Kgf)
Force accuracy: Depends on the load cell used.
Force measuring amplifier: Built in
Controller: Built in
Test speed: 5~1000 mm/min.
Speed changing: Numeric input (Settable on the PC)
Stroke: 100 mm or more (when 90-deg peeling jig installed),390mm (when no jig installed)
Displacement resolution: 0.01 mm
Display accuracy: ±0.5 mm
Table size: W174 x D200 mm
Mass: Approx. 35 kg
Dimensions: W300 x D400 x H830 mm
Power supply: Single phase, 100VAC – 240VAC 3A
Standard set: Tester, load cell 1 piece, software
Options: Peeling jig, additional load cell
