Gain: 2 dBi
VSWR: 3:1
Width: 41.24 mm
Height: 0.304 mm
Length: 29.6 mm
Impedance: 50 Ohms
Cable Type: 350 mm RF1.37 mm
Application: Cellular Application, Wireless Application
Unit Weight: 3.300 g
Cable Length: 350 mm
Power Rating: 3 W
Mounting Style: Adhesive Mount
Electrical Type: Embedded
Number of Bands: 2 Band
Center Frequency: 2400 MHz, 2450 MHz, 2500 MHz, 2700 MHz, 3300 MHz, 3500 MHz, 5200 MHz, 5500 MHz, 5800 MHz
Mechanical Style: PCB Trace
Maximum Frequency: 5.875 GHz
Minimum Frequency: 2.3 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: IPEX MHF
Protocol - WiFi - 802.11: 802.11, WLAN, WiFi, WiMAX
Protocol - Cellular, NBIoT, LTE: 4G, Cellular (NBIoT, LTE)
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
