Color: Black
Gender: Jack (Female)
IP Rating: IP40
Shielding: Shielded
USOC Codes: RJ45
Application: 1000 Base-T
Unit Weight: 17 g
Configuration: 1x1
Mating Cycles: 1000 Cycle
Tab Direction: Tab Down
Current Rating: 1.5 A
Mounting Angle: Straight
Mounting Style: Flange Mount
Voltage Rating: 125 VAC
Contact Plating: Gold
LED L / R Color: Green / Yellow
Number of Ports: 1 Port
Contact Material: Phosphor Bronze
Termination Style: Solder
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
Performance Category: Cat 5e
Insulation Resistance: 500 MOhms
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Number of Positions / Contacts per Port: 8P8C
