Range: 20 Ω
Nominal Current: 1 mA
Resolution: .001 Ω
Accuracy: ± .25% of reading & range
Range:200 Ω
Nominal Current: .1 mA
Resolution:.01 Ω
Accuracy:± .25% of reading & range
Terminal: Trident
Display:4 1/2 digit LCD
Update: 1 reading per 3 seconds
Power: 4ea AA 1.5 VDC alkaline batteries
Weight: 3 lbs.
Dimensions: 7.69″ x 7.56″ x 3″
Max. Internal Voltage: 5 VDC
Open Circuit: ~5 VDC
Operating Temperature Range: -20° to 50° C
Storage Temperature Range: -40° to 75° C
Temperature Coefficient: ± .025% per 1° C
Max. Input Voltage: 250 VDC
