Width: 1.25 mm
Height: 0.9 mm
Length: 2 mm
Shutdown: No Shutdown
Output Type: LVDS
Supply Type: Single
Unit Weight: 28 mg
Response Time: 1.6 ns
Mounting Style: SMD/SMT
Comparator Type: General Purpose
Development Kit: EVAL-ADCMP604BKSZ
Voltage Gain dB: 62 dB
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.5 V
Pd - Power Dissipation: 42 mW
Propagation Delay Time: 1.5 ns
Ib - Input Bias Current: 5 uA
Operating Supply Current: 17 mA
Operating Supply Voltage: 3 V, 5 V
Output Current per Channel: 50 mA
Vos - Input Offset Voltage: 5 mV
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
CMRR - Common Mode Rejection Ratio: 50 dB
PSRR - Power Supply Rejection Ratio: 50 dB
