Measurement range: 0.1 - 1000 μm
Measurement principle: Mie scattering theory and Fraunhofer diffraction theory
Accuracy: ≤ 1% (D50 of certified reference material)
Lens protection: Dual air curtain
Pressure of carrier gas: 0.4 - 0.8 MPa
Airflow volume: ≥ 1000 L/min
Laser power: Semiconductor laser
Number of detector: 68
Carrier gas: Compressed air/inert gas
Communication protocol: TCP, Modbus RTU, 4 - 20 mA
Protection: IP65
Sample required per measurement: 2 - 20 g
Power: AC220 V, 50 / 60 Hz, 90 W
Dimension: 800 (L) x 280 (W) x 280 (H) mm (Main unit)
Weight: 21 kg (Main unit)
