Particle Size Measurement
Size range (Diameter): 0.4 nm – 9 um*
Sample volume: 25 μL – 1 mL
Measurement angle: 90°
Analysis algorithm: Cumulant, General Mode, CONTIN
Sensitivity: Toluene > 20 kcps
Molecular Weight Measurement
Molecular weight range: 342 Da – 2 x 107 Da
Viscosity
Viscosity range: 0.01 cp – 100 cp*
System Parameters
Temperature control range: -10°C - 110°C ±0.1°C
Condensation control: Dry air or nitrogen
Standard laser : 50 mW High-performance solid-state laser, 671 nm
Correlator: 100 ns – 8000 s, Up to 4000 channels, 1011 linear range
Detector APD (avalanche photodiode)
Intensity control: 0.01% - 100%, manual or automatic
Signal Transduction: Single-mode Optical Fiber
Dimensions: Length, width and height 68 x 44 x 23 cm (18 kg)
Power Requirements: 220V, 60W
