Frequency Range: 10 MHz to 43.5 GHz
Frequency Resolution: 0.1Hz
Frequency Accuracy : ±1×10-7 (23℃±3℃)
Max. Output Power
• 10MHz – 50MHz: +12dBm • 50MHz – 250MHz: +13dBm
• 250MHz – 1GHz: +13dBm • 1GHz – 10GHz: +13dBm
• 10GHz – 20GHz: +10dBm • 20GHz – 35GHz: +8dBm
• 35GHz – 43.5GHz: +3dBm
Power Sweep Range
• 10MHz – 50MHz: 30dB • 50MHz – 10GHz: 33dB
• 10GHz – 20GHz: 30dB • 20GHz – 35GHz: 28dB
• 35GHz – 43.5GHz: 28dB
Dynamic Range
• 10MHz – 50MHz: 90dB • 50MHz – 250MHz: 98dB
• 250MHz – 1GHz: 115dB • 1GHz – 10GHz: 128dB
• 10GHz – 20GHz: 122dB • 20GHz – 35GHz: 118dB
• 35GHz – 43.5GHz: 110dB
Effective Directivity: 42dB (10MHz – 2GHz), 45dB (2GHz – 20GHz), 38dB (20GHz – 43.5GHz)
Effective Source Match: 40dB (10MHz – 2GHz), 30dB (2GHz – 20GHz), 30dB (20GHz – 43.5GHz)
Effective Load Match: 42dB (10MHz – 2GHz), 45dB (2GHz – 20GHz), 36dB (20GHz – 43.5GHz)
Port Connection: 2.4mm (male)
System Impedance: 50Ω
Number Of Measuring Ports: 2/4 ports
Peripheral Interface: USB,GPIB,VGA,LAN,HDMI interface
Operating System: Windows 7
Display: 12.1inch 16:10 screen (Equipped with capacitive touch function)
Size
• 2-Port Instrument:
W´H´D≈426mm×266mm×400mm(No soles, no handles)
W´H´D≈516mm×280mm×490mm(include soles and handles)
• 4-Port Instrument:
W´H´D≈426mm×266mm×450mm(No soles, no handles)
W´H´D≈516mm×280mm×540mm(include soles and handles)
Max. Power Consumption: 300W
Power Supply: 50Hz 220V or 50Hz/60Hz 110V AC
Max. Weight: 28kg
See more detail information in the Datasheet
