Acoustic Specifications
Microphone array: 200 channels MEMS microphone
Frequency range: 2k - 100k Hz
SPL range: 28 - 132 dB
Minimum detectable leak: 10 m 2.7 bar 0.0029 L/min, 0.5 m 1.9 bar 0.0028 L/min
Test distance: 0.5 - 200 m (1 - 656 ft)
Camera
Camera FOV: 66°
Focal length: 4.3 mm (0.17 inches)
Camea pixel: 13M pixel
Digital zoom: 1x - 6x
Fill light: LED * 4
Display: Resolution 1920 * 1200
Size: 8 inches
Touchscreen: Capacitive touchscreen
Brightness: 600 nits, support auto and manual adjustment
Storage
Storage: 64G internal，64G external TF card
Data format: .jpg (picture)，.mp4 (video)，.wav (audio)，.cdat（data）
Video length: 10 minutes
Data export: USB-C，Wi-Fi，TF card
Battery
Battery capacity: 6600mAh @7.2V
Battery type: Smart battery with indicator，replaceable
Battery life: Up to 5 hours
General Specifications
Size: 270 * 190 * 51 mm (10.6 * 7.5 * 2.0 inches)
Weight: 1.4 kg (3 lbs)
Wi-Fi: 802.11a/b/g/n/ac
Bluetooth: BT 5.2
GNSS: GPS+BDS+GLONASS+GALILEO+QZSS
Operating temp.: -20 - +50℃, 10 - 95%, no cond.
Storage temp.: -20 - +70 ℃, 10 - 95%, no cond.
IP rated: IP54
Storage size: 64G internal，64G external
Certificate
Safety: IEC 61010-1
EMC: IEC 61326-1
Vibration: 2g，IEC 60068-2-6
Shock: 25g，IEC 60068-2-27
Drop test: 1.2 m (4 ft)
Software
Function
Multi-point imaging，directional focus，distance measurement，leak volume estimation，PRPD spectrum，type recongnition，picture labeling，report export，and etc.
Hardware port
USB-C 1: USB 3.0 for charging，HDMI，data export
USB-C 2: USB 2.0 for data export，USB sensor
3.5 mm audio jack: Headphone output
TF card slot: External storage
SIM card slot: Inserting a 4G/5G network communication card
Analog input: 4 channels，20 - 100k Hz，IEPE，phantom power supply
Language
Language: Chinese, English, Korean, French, Japanese, Russian, German, Italian, EU Spanish, Portuguese, Hungarian, Dutch, Cambodian, Vietnamese, Turkish, Polish
