Analog Part:
Input Sensitivity: Min. 0.1 uV/Digit
Load Cell Excitation: DC 5V
Non-Linearity: 0.001% of Full Scale
Input Signal: Max 3.0 mV/V
A/D Method & Sampling : Max 60 times/sec, Sigma-Delta
Resolution: Internal 1/1,000,000, Display: 1/20,000
Display Part:
Main Display: 7 Segment, 6 Digit Red FND, H: 16.2mm
Status LED: STEDY, ZERO, TARE, OUT1, OUT2, OUT3, OUT4
Under Zero balance: Minus (-) Display
General Part:
Power Supply: Free Voltage DC24V/8W(SMPS)
Operating Condition: Temperature: -10°C~+40°C, Humidity: Under 85% RH
Size/Weight: 96(W) x 48(H) x 135(D) mm / 0.9 kg
Interface: Standard RS422&RS485 Special Order: RS-232C
External Input: 4 EA
Relay Output: 4 EA
Analog Output: 4~20mA, 0~10V(User Selectable)
