Pixel pitch (mm): 2.3
Number of rows per DM (pcs): 8
Number of read-out channels per DM (pcs): 512
Max DM quantity : 80
Max number of read-out channels for the system @ max 80 DMs (pcs): 40960
DM active area length (X) (mm) : 147.2
DM active area width (Z) (mm): 20.1
Pixel absorption length (Y) (mm): 40
Max object scanning speed (km/h): 70 / 36
Max scanning speed : 1,000 lines/sec (1 kHz pulse rate)
Min integration time (per pulse) : 100 us
Scintillator material : Cesium Iodide, CsI (Tl)
Min. range (pC/pixel): 0.75
Max. range (pC/pixel): 95.25
Range step (pC/pixel): 0.75
Number of sensitivity setting steps (pcs): 127
A/D resolution (bits): 20
Data interface options : Gigabit Ethernet / 10GbE Optical Fiber
